Ni35cr20 Resistance Alloy Rod Alloy Welding Rods With Excellent Weldability

Brand Name : Huona

Model Number : NiCr3520

Certification : ISO9001, RoHS

Place of Origin : China

MOQ : 1KG

Price : Need to negotiate

Payment Terms : T/T

Supply Ability : 100 Ton/Month

Delivery Time : Around a week

Packaging Details : Carton, Wooden Case

Product name : Ni35cr20 Bar/Rod

Product type : Bar/ Rod

Product material : 35%Ni 20%Cr

Product characteristics : high resistivity, good oxidation resistance ,good form stability and good ductility and excellent weldability

Shape : Rod/Bar

Sample : Support samples

Contact Now

Product Description

Basic Info.

Model NO.
Ni35Cr20 Rod
Purity
35%
Alloy
NiCr Alloy
Type
Resistance Alloy Rod
Powder
Not Powder
The Highest Use Temperature
1100℃
Resisivity
1.04uΩ/M
Density
7.9g/cm3
Transport Package
Wooden Cases or Cartons
Specification
Support customization
Trademark
HUONA
Origin
China
HS Code
7505220000
Production Capacity
2000Tons/Year

Product Description

Ni35cr20 Resistance Alloy Rod

1.About Nichrome Ni35Cr20 Rod
Nichrome alloy Ni35Cr20 characterized by high resistivity, good oxidation resistance ,good form stability and good ductility and excellent weldability. It is suitable for use at temperatures up to 1100°C.

2.Ni35Cr20 has many other Grade name:
Cr20Ni35, Chromel D, N4, Chromax, HAI-NiCr 40, Tophet D, Resistohm 40, Cronifer III, 35-20 Ni-Cr, Alloy D, MWS-610, Stablohm 610

3.Chemical Composition of Ni35Cr20
C P S Mn Si Cr Ni Al Fe Other
Max
0.08 0.02 0.015 0.60 0.75~1.60 18.0~21.0 34.0~37.0 Max 0.50 Bal. -

4.Typical Mechanical properties of Nicr3520
Yield strength Tensile Strength Elongation
Mpa Mpa %
370 750 35

5.Temperature Factors Of Electrical Resistivity
20ºC 100ºC 200ºC 300ºC 400ºC 500ºC 600ºC
1 1.011 1.024 1.038 1.052 1.064 1.069
700ºC 800ºC 900ºC 1000ºC 1100ºC 1200ºC 1300ºC
1.073 1.078 1.088 1.095 1.109 - -

6.All shape of Nichrome
Wire, ribbon( flat wire ), strip, bar, plate, tube
7.size of Ni35Cr20

Wire 0.018mm-10mm
Ribbon 0.05*0.2mm-2.0*6.0mm
Strip 0.5*5.0mm-5.0*250mm
Bar 10-100mm


Ni35cr20 Resistance Alloy Rod Alloy Welding Rods With Excellent Weldability
